| Specyfication |     Charger  |
| Features | Suitable for 12V and 24V lead-acid wet, gel, and AGM batteries
Battery capacity: 1.2Ah – 180Ah(12V), 1.2Ah-90Ah (24V) Protections: Short-circuit / Overvoltage Selectable charging current: 1A/3A/ 6A (12V), 1A/3A (24V) LCD display, user-friendly interface, microprocessor controlled Battery status detection, desulfation mode |
| Input | Input voltage: 220-240V (50Hz)
Input current (max.): 0.75A/230VAC |
| Output | Output voltage (max.): 14.7V - output current 1A / 3A / 6A (selectable)
Output voltage (max.): 29.4V - output current 1A / 3A (selectable) |
| Protection | Overvoltage >16VDC (12V mode), >32V (24V mode), output voltage disconnection
Short-circuit: Output voltage disconnection, display notification |
| Working Environment | Operating temperature: -5 to +40 degrees celsius
Operating humidity: 20-90% (relative humidity, non-condensing) Storage temperature and humidity: -10 to +60 degrees celsius, 10-95% (relative humidity, non-condensing) |
| Safety Standards | Safety standards EN 60335-2-29:2004 + A2:2010; EN 60335-1:2012 + A11:2014
EMC standards EN 55014-1, EN 61000-3-3, EN 55014-2, EN 61000-3-3, EN-61000-3-2 |
